Photo Index - Burke Machine Tool Co. - Burke # 1

Machinery Photo Index

Manufactured/Badged by:
Burke Machine Tool Co.
Cleveland, OH; Conneaut, OH; Cincinnati, OH

True Manufacturer:
Burke Machine Tool Co., Cleveland, OH; Conneaut, OH; Cincinnati, OH

Machine Specifications
Machine Class:	Metal Working Machinery
Machine Type:	Mill, Horizontal
Machine Size:	Approx 3"x12"
Submitted By:	Peter Karas

Machine Specifications
Description/Model:	Burke # 1
Date of Manufacturer:	1920's to 1950's ?
Serial Number:	-
Last Updated	4/9/2016 5:39:22 PM

Comments:

I picked this machine up from a fellow in Sarnia for 100 dollars. A Burke #1 mill. It's been highly modified by a machinist to have full 3 axis control. (Normally these machines had lever feed.) No graduations on the handwheels but I am sure I can use a dial indicator for measurement.

The spindle and arbor have been redone with an MT2 taper. Need to rig up a drive system, and use it to mill some slots and such. Maybe get a micro-sized milling vise.

A fun little machine.

Photo 1:

Comments: Overall shot.
Source:

Direct Link
IMG Code

Photo 2:

Comments: Table and handwheels.
Source:

Direct Link
IMG Code

Photo 3:

Comments: 3-En-Une Oil for scale.
Source:

Direct Link
IMG Code

Photo 4:

Comments: Separate handwheel assembly controls table elevation.
Source:

Direct Link
IMG Code

Photo 5:

Comments: Arbor and drawbar. (Spacers on Arbor)
Source:

Direct Link
IMG Code
