Photo Index - Elgin Tool Works - bench top

Machinery Photo Index

Manufactured/Badged by:
Elgin Tool Works
Elgin, IL; Chicago, IL

Machine Specifications
Machine Class:	Metal Working Machinery
Machine Type:	Lathe, Metal
Machine Size:	small bench top
Submitted By:	jordie field

Machine Specifications
Description/Model:	bench top
Date of Manufacturer:	1905/ or earlier
Serial Number:	none seen
Last Updated	6/22/2014 10:26:52 PM

Comments:

CList find. Very early model-Elgin lathe. Made in the earliest part of the 20th century in Elgin Illinois. Been looking for this for awhile, or one like it. Much dedicated time on the computer while family is watching america's biggest looser, or something like that. Anyway...fitted with a (4C) cataract collet system. Cataract later became hardings I think?? A Quick release chuck that 3 jaw chuck slots in. Came with a three jaw chuck, tool rest, 35 collets, stock centering device and many other tooling parts. Motor is from the "Square D" factory of Milwaukee Wisconsin. Leather belt variable speed cone pulleys. is in. This was found in an airplane hanger in "Kenosha" Wisconsin. The PO restored vintage airplanes, very interesting gentleman who has tons of experience. He was selling off some of his equipment. The machine is in as found condition and needs no restoration. Hurrah!!!!

Photo 1:

Comments: front view
Source: my i tool

Direct Link
IMG Code

Photo 2:

Comments: X/Y table slide with lantern. no markings
Source: my I tool

Direct Link
IMG Code

Photo 3:

Comments: three step cone pulleys and switch
Source: my I tool

Direct Link
IMG Code

Photo 4:

Comments: motor plus pulley system in as found condition
Source: my I tool

Direct Link
IMG Code

Photo 5:

Comments: elegant tail stock (Cataract style, or Cataract)
Source: my I tool

Direct Link
IMG Code

Photo 6:

Comments: doubled this one,
Source: my I tool

Direct Link
IMG Code
